Premium motorized roll-up LED screen with COB+GOB protection, flexible panel technology & space-saving automatic storage system
The 135-Inch Rollable LED Display from DLED Factory is a revolutionary motorized flexible LED screen that combines stunning visual performance with intelligent space-saving design. Unlike traditional fixed LED walls, this display rolls up automatically into its compact base unit when not in use — completely hidden from view, protecting the panel and freeing your space.
Built with COB + GOB dual-protection technology, the flexible LED panel withstands up to 2.5 tons of pressure, making it highly resistant to impact, scratches, dust, and moisture. The ultra-thin 13mm profile and lightweight construction make it ideal for rental companies, event businesses, retail stores, corporate boardrooms, and high-end exhibitions.
| Specification | Details |
|---|---|
| 📋 GENERAL | |
| Brand | DLED Factory (Guangzhou Lianxian) |
| Model | Rollable LED Display 135” |
| Screen Size | 135 inches diagonal |
| Display Type | Indoor flexible rollable LED wall |
| LED Technology | COB + GOB dual protection |
| Roll System | Motorized automatic roll-up & deploy |
| Installation | Floor-standing base unit — no wall mounting needed |
| 🖥️ DISPLAY | |
| Screen Dimensions | Approx. 3000 × 1688 mm (135″ diagonal) |
| Aspect Ratio | 16:9 |
| Resolution | Full HD 1920×1080 / 4K compatible |
| Pixel Pitch Options | P1.25 / P1.56 / P1.95 / P2.6 (fine pitch) |
| Brightness | ≥ 800 nits (indoor high brightness) |
| Contrast Ratio | ≥ 5000:1 |
| Color Depth | 16-bit — 65,536 grayscale levels |
| Refresh Rate | ≥ 3840 Hz |
| Viewing Angle H/V | 160° / 160° |
| Color Gamut | Standard 100% BT.709 / HDR compatible |
| HDR Support | Yes — HDR display effect |
| 🛡️ PROTECTION & BUILD | |
| LED Technology | COB (Chip-On-Board) + GOB (Glue-On-Board) |
| Panel Thickness | Ultra-thin — approx. 13mm |
| Weight (per sqm) | 15–18 kg/m² (lightweight flexible structure) |
| Pressure Resistance | Up to 2.5 tons (GOB protection) |
| IP Rating | IP21 (splash-resistant) |
| Impact Resistance | IK63 — anti-collision protection |
| Frame Material | Carbon fiber + lightweight alloy |
| Bending Radius | Minimum R500mm (optional curved installation) |
| Lifespan | ≥ 100,000 hours |
| Operating Temp | -10°C to +45°C |
| Humidity | 10% – 90% RH |
| 🔌 CONNECTIVITY | |
| Input Ports | HDMI, USB, LAN (RJ45) |
| Video Processor | External video processor supported |
| Compatible Sources | Laptops, media players, conference systems, digital signage |
| Control System | NovaStar / standard LED control systems |
| Content Formats | MP4, AVI, JPG, PNG, PPT, live signals |
| Audio | Optional built-in speakers available |
| ⚡ POWER | |
| Input Voltage | AC 110V – 240V / 50-60Hz (global) |
| Average Power | ~200–400W (depending on content) |
| Energy Saving | Yes — auto brightness adjustment |
| 🚚 TRANSPORT & MAINTENANCE | |
| Maintenance Access | Front & rear service access |
| Transport Case | Heavy-duty flight case with wheels |
| Setup Time | Single person — under 5 minutes |
| Certifications | CE, RoHS, FCC |
| Warranty | 1 Year Manufacturer Warranty |
| Shipping | Sea Freight or DHL Express — Worldwide from Guangzhou |
